Lasers in Semiconductor Inspection – Training Services

Lasers in Semiconductor Inspection – Training Services focuses on the use of laser-based techniques for high-precision inspection and quality control in semiconductor manufacturing. The training covers methods such as laser scattering, confocal microscopy, and photoluminescence for detecting defects, measuring film thickness, and evaluating wafer surface quality. Participants will learn about system setup, calibration, and data interpretation to ensure manufacturing accuracy and reliability. Applications in IC fabrication, nanostructure inspection, and process optimization are emphasized, equipping learners with essential skills for advanced semiconductor production.
